Phase Maintenance Stand (Sikorsky S-92)
Get 360-degree access to your helicopter maintenance access points with the Heli Grade Solutions Phase Maintenace Stand. This stand was designed for the Sikorsky S-92 aircraft for engine, transmission, main rotor, tail rotor and fuselage access. Aircraft technicians use this stand for full phase maintenance and a complete overhaul of the aircraft.
This full phase maintenance fuselage wrap-around stand offers a 1500 lbs load capacity per side and includes removable handrails and 20″ locking slide-out platform extensions. Our in-house engineering team designs these American-made Heli Grade Solutions to meet and exceed compliance standards, including ANSI, OSHA and Cal/OSHA.
Factory Supply Aviation Access Equipment has been engineered to fit multiple aircraft types and access points. Please note that in addition to the aircraft models listed, our equipment meets the criteria of numerous aircraft models that match the access point specifications of our tested equipment. Contact our specialists to confirm if your aircraft is applicable or for customization options.
![Phase maintenance stand [helicopter]](https://www.factorysupply.com/wp-content/uploads/2021/09/FSH-S92-PM-300x300.png)
Phase Maintenance Stand (Sikorsky S-92)
- Model #: FSH-S92-PM
- Load Capacity: 1500 lbs per side
- Deck Capacity: 500 lbs lower/300 lbs folding platform
Phase Maintenance Stand (Sikorsky S-92)
- Model #: FSH-S92-PM
- Height: Fuse: 150”; Tail: 162”
- Width: Fuse: 66”; Tail: 162”
- Length: Fuse: 410”; Tail: 168”
- Weight: 6,125 lbs
- Shipping info: 40’ Shipping container
- Upper deck height: Fuse: 108”; Tail: 120”
- Lower deck height: Tail: 72”
- Vertical clearance: Fuse: 150”; Tail: 162”
- Platform dimensions: Fuse: 42” x 410” Tail: 162” x 90”
- Load capacity: 1500 lbs per side
- Deck capacity: 500 lbs lower/300 lbs folding platform
- Stair capacity: 250 lbs
- Step width: 24”
- Material: Aluminum
- Certifications: OSHA 1926. 1053; ANSI-ASC 14.2-2017
- Helicopter application: Sikorsky S-92
- Accessories: Composite plate decking and diamond plate decking
- Full phase maintenance fuselage wrap around stands
- Removable hand rails
- Foot actuated hydraulic pump
- 20″ locking slide out platform extensions
Sikorsky S-92
Build Your System
"*" indicates required fields
Access Every Angle
360 degree maintenance coverage
- Phase maintenance dock
- Blade rack
- Parts Rack
- Engine access stand
- Tail access stand
![360 degree maintenance platform, blade rack and parts rack [helicopter]](https://www.factorysupply.com/wp-content/uploads/2021/09/FSH-UH60-PM-3D4-removebg-preview-1.png)
Rotary Wing Maintenance
Safety in the air starts on the ground
Full fall restraint provisions
Multi-functional design
Customizable to individual operational requirements
Engineered to meet or exceed all OSHA and ANSI safety standards
2 year bumper to bumper warranty
Safe access to maintenance and inspection points
In-house design and engineering team
World class fabrication for multiple applications
DESIGN
From inception, through to design, fabrication, and installation; Factory Supply Heli Grade Solutions specializes in standard and custom rotary-wing Phase Maintenance Stands. Working alongside our valued clients in the Commercial, Military, and Private Aircraft sectors, we have been recognized as a leader in quality, innovation, dependability and customer service. Our products are designed to safely access maintenance inspection points, perform painting, assembly, overhaul and repairs.
Our specialized solutions allow maintenance personnel to work both safely and efficiently while protecting the aircraft. Our maintenance stands are constructed with premium American materials and products, while exceeding all regulatory requirements including OSHA and ANSI.
Regulatory and Compliance
All Factory Supply products are engineered, designed, built and tested in accordance with OSHA and ANSI regulations.
Many of our products have also been tested, and meet or exceed BS EN 131.7, DIN EN 12312-8, EN 1915-1, and include CE certifications.
Built for safety and ease of use
Our stands assist in preventing falls as gaps are eliminated with platform customization and each stand features padding on the frame and platform to protect the helicopter from accidental bumps and also potential employee head injuries.
A focus on the finer details
Features of our maintenance stands include electric hook ups, pneumatic/air hook-ups, work or service trays, as well as optional composite non-slip decking surface.
