Stackers
Safely lift and stack products with an ergonomic stacker designed so you can avoid heavy lifting, repetitive strain, and other common employee injuries.
These pieces of equipment can perform a number of functions, the two main functions are;
Ergonomic Work Positioners
Designed to lift heavy loads, move them through your facility and place them at different elevations.
Hand Pump Stackers
These hand pump stackers have a compact and durable design helping to ensure that not only are they easy to maneuver, but they can fit into crowded areas as well. In addition, they utilize top quality hydraulic pumps to ensure they can easily lift product weighing up to 2,200 lbs.
Injury incident: Accident Report Detail
Models
Ergonomic Work Positioners
These ergonomic product positioners will make your life that much easier as they will remove the tough part of moving product throughout your facility. Available in a variety of different configurations, there is a model for every application need.
| Model No. | Capacity (Lbs.) | Lift Height (In.) | Low’d Fork Height (In.) | Fork Width (In.) | Fork Length (In.) | Straddle I.D. (In.) |
|---|---|---|---|---|---|---|
| SPEW36-10 | 1,000 | 36 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW36-20 | 2,000 | 36 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW36-30 | 3,000 | 36 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW48-10 | 1,000 | 48 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW48-20 | 2,000 | 48 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW48-30 | 3,000 | 48 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW60-10 | 1,000 | 60 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW60-20 | 2,000 | 60 | 3 1/4 | 26 1/2 | 42 | 50 |
| SPEW60-30 | 3,000 | 60 | 3 1/4 | 26 1/2 | 42 | 50 |
Hand Pump Stackers
These hand pump stackers have a compact and durable design helping to ensure that not only are they easy to maneuver, but they can fit into crowded areas as well. In addition, they utilize top quality hydraulic pumps to ensure they can easily lift product weighing up to 2,200 lbs.
| Model | HPS11-59 | HPS22-59 | HPS11-98 | Fork Width (In.) | Fork Length (In.) | Straddle I.D. (In.) |
|---|---|---|---|---|---|---|
| Capacity (Lbs.) | 2,000 | 2,200 | 2,200 | 26 1/2 | 42 | 50 |
| Travel Per Stroke | 0.8″ | 0.5″ | 0.5″ | 26 1/2 | 42 | 50 |
| Lift Height (In.) | 59 | 59 | 98 | 26 1/2 | 42 | 50 |
| Min Fork Height (In.) | 4 | 3.5 | 3.5 | 26 1/2 | 42 | 50 |
| O.A. Fork Width (In.) | 21 | 21 | 21 | 26 1/2 | 42 | 50 |
| O.A. Fork Length (IN.) | 46 | 46 | 46 | 26 1/2 | 42 | 50 |
| Load Wheel | 3.2″ DIA | 3.2″ DIA | 3.2″ DIA | 26 1/2 | 42 | 50 |
| Steering Wheel (In.) | 6 | 6 | 6 | 26 1/2 | 42 | 50 |
| Weight (Lbs.) | 462 | 484 | 726 | 26 1/2 | 42 | 50 |
- Drastic reduction in heavy/repetitive lifting
- Customized for your specific application, designed to work with your product(s)
- Reduction in workplace illness/injury claims, resulting in lower insurance costs
- Allows for diversity/adaptability on the job, more workers are now able to complete the task without physical limitations being an issue
- Our systems pay for themselves via productivity and efficiency increases
- Weight and capacity ranges are considered during the design process, our systems can handle multiple weights, textures and products without altering the system
- Designed to work in your specific facilities conditions, such as high heat, dust, humidity, moisture etc.
- Pulp and Paper
- Textile
- Packaging
- Pharmaceutical / Medical
- Food and Beverage
- Manufacturing
- Econolift
- Bishammon
- Vestil
- Paper
- Plastic
- Film
- Textiles
- Bottling
- packaging
- etc
