Lift-N-Glide Hybrid Lifter
attachments
EXPAND-O-TURN
Electric core expander for paper and film rolls.
Squeeze-O-Turn
Lifting device to support drum handling and goods requiring rotation.
Lift-O-Turn
End-effector that can be equipped with different arms to handle various products that need rotating.
Vacuum
End-effector that features adjustable magnets allowing lifting of up to 200 lbs.
forks
Fixed or adjustable forks for material handling where space is limited.
Load Platform
Allow operators to handle totes, boxes, roles and pails. Available in standard and custom sizes.
Core Probe
Available in a fixed or wheeled model, used to handle rolls from pick up to drop off.
Custom
We also offer custom solutions to meet your individual needs.
Lift-N-Glide Features and benefits
| Features and Benefits | |
|---|---|
| Lift Capacity |
|
| Anodized Aluminum Profiles |
|
| Steel (Powder Coated Paint-Optional SS) |
|
| Bolted Connections | |
| Standard and Custom Length Lift Masts | |
| Lift Mast Slip Clutch on Down Movement |
|
| Current Limiting (No Limit Switches) |
|
| Totally Enclosed Lift Mast with Ball Screw |
|
| Electronic Power Pack |
|
| 360° Swivel for Load Handling Access | |
| Ceiling Hung or Free Standing | |
| Detachable Remote Controller |
|
| Adjustable Handlebar |
|
Lift-N-Glide Specifications
| Specifications | Details |
|---|---|
| Lift Stroke (19000 Series Mast) | 54", 73.75", 93.25" |
| Lift Speed | 4" per Second |
| Lift Capacity | Up to 500 lbs |
| Power Requirements | 24V/DC |
| AC/DC Converter or Charger | 110V/AC |
| MovoMech® Rail | Manual |
| Powered Options | Electrical or Pneumatic |
| Rotator | 360° With or Without Brake |
| Available End-Effector Options |
|
Regulations
| All of our Material Handling solutions either meet or exceed all applicable regulations which include; OSHA, ANSI and ASME B30.20. |
Resources
Vacuum Lifting 101
Explore the fundamentals of vacuum lifting technology and its applications in material handling with this comprehensive article.
The Lifting Equation
Learn the lifting equation and gain a deeper understanding of safe and efficient lifting practices in material handling.
Hydraulic Lift Tables
Discover the seven key advantages of using a hydraulic lift table for various material handling tasks in this insightful article.
